1. Adopting a 32-bit embedded microprocessor as the main control core, embedded with a mini operating system;
2. Constant voltage detection, high accuracy, fast measurement speed, stable and reliable;
3. Real time electrolysis curve chart, observing the status of reagents at any time;
4. Equipped with power-off storage function, it can automatically save test results and store up to 100 sets of data;
5. Large screen color touch LCD display, easy to operate and user-friendly interface;
6. Supports 6 calculation formulas, making data calculation convenient and fast;
7. It has the advantages of high measurement accuracy, fast speed, stable and reliable measurement data, etc
Technical Parameter
name |
Indicator |
measuring range |
1μg-200mg |
measurement accuracy |
3μg-1000μg ≤ ± 3μg ≥ 1000μg ≤ ± 0.3% |
electrolytic current |
0-400mA |
resolution |
0.1μg |
supply voltage |
AC 220 V ±10% |
Power frequency |
50 Hz ±2% |
Power |
≤ 35w |
Temperature |
10~40℃ |
For humidity |
<85 % RH |
Width x Height x Depth |
350m*260mm*180mm |
Net weight |
~ 8kg |
